QCustomAreaChart

Area chart implementation using the modular architecture.

Qt Designer compatible with property exposure.

At a glance


Tier	Free (GPLv3)
Import	`from Custom_Widgets.QCustomCharts.QCustomAreaChart import QCustomAreaChart`
Qt Designer	Yes — drag it from the palette

Quick start

from Custom_Widgets.QCustomCharts.QCustomAreaChart import QCustomAreaChart

widget = QCustomAreaChart()
widget.categoriesCsv = "Jan,Feb,Mar,Apr,May,Jun"
widget.seriesCsv = "Revenue=12,19,15,24,22,30;Costs=8,11,9,14,13,17"
_chartPresentation(w, theme, "Revenue vs costs", "Month", "$k")

That is the exact code behind the screenshot above.

Dark theme

Colours come from the design tokens, so the widget follows the app theme with no extra work.

Properties

Every property below is settable in code and in Qt Designer.

Property	Type	Default
`gradientFill`	`bool`	`True`
`gradientType`	`string`	`vertical`
`baselineValue`	`float`	`0.0`
`stackedArea`	`bool`	`False`
`percentageArea`	`bool`	`False`
`fillOpacity`	`float`	`0.3`
`xAxisTitle`	`string`	`X Axis`
`yAxisTitle`	`string`	`Y Axis`
`autoScale`	`bool`	`True`
`showCrosshair`	`bool`	`True`
`crosshairColor`	`color`	`#000000`
`crosshairWidth`	`float`	`1.0`
`showGrid`	`bool`	`True`
`gridColor`	`color`	`#c8c8c8`
`showLegend`	`bool`	`True`
`showDataPoints`	`bool`	`True`
`fillArea`	`bool`	`True`
`enableShadow`	`bool`	`False`
`shadowBlur`	`int`	`15`
`highlightSize`	`int`	`8`
`markerSize`	`float`	`8.0`
`showFooter`	`bool`	`True`
`defaultLineStyle`	`int`	`0`
`defaultMarkerStyle`	`int`	`6`
`chartTitle`	`string`	`Area Chart`
`animationEnabled`	`bool`	`True`
`animationDuration`	`int`	`1000`
`antialiasing`	`bool`	`True`
`showToolbar`	`bool`	`False`
`tooltipsEnabled`	`bool`	`True`
`tooltipDelay`	`int`	`500`
`tooltipDuration`	`int`	`5000`
`theme`	`int`	`0`
`legendPosition`	`int`	`1`
`legendFontSize`	`int`	`8`
`legendBackgroundVisible`	`bool`	`False`
`compactMode`	`bool`	`False`
`seriesCsv`	`string`	—
`categoriesCsv`	`string`	—

Signals

Signal
`chartExportComplete(QString,bool)`
`dataPointClicked(double,double,QString)`
`dataPointHovered(double,double,QString)`
`legendPositionChanged(QString)`
`seriesAdded(QString)`
`seriesRemoved(QString)`

Methods

Method	Description
`addSeries(name: str, data: List[Tuple[float, float]], color: PySide6.QtGui.QColor	None = None, visible: bool = True, line_style: str = 'solid', line_width: float = 2.0, marker_style: str = 'none', marker_size: float = None, **kwargs) -> bool`
`appendToSeries(name: str, points: List[Tuple[float, float]]) -> bool`	Append points to an existing series
`applyCustomPalette(palette: PySide6.QtGui.QPalette)`	Apply a custom palette to the chart (for App Theme)
`areaBorderEdges() -> bool`	Whether the full area outline is stroked (see setAreaBorderEdges).
`baselineValue(args, *kwargs)`	Get baseline value
`chartExportComplete(...)`	Chart export complete.
`clearData()`	Clear all chart data (compatibility method)
`dataPointClicked(...)`	Data point clicked.
`dataPointHovered(...)`	Data point hovered.
`exportToClipboard()`	Export chart to clipboard
`exportToFile(format: str = None, filename: str = None)`	Export chart to file
`fillOpacity(args, *kwargs)`	Get fill opacity
`generateExampleData(example_type: str = 'sine_wave')`	Generate example data for testing.
`getAvailableLegendPositions() -> List[str]`	Get list of available legend positions
`getAvailableThemes() -> List[str]`	Get list of available theme names
`getBaselineValue() -> float`	Get the baseline value
`getFillOpacity() -> float`	Get fill opacity
`getGradientType() -> str`	Get gradient type
`getLegendAlignment() -> PySide6.QtCore.Qt.AlignmentFlag`	Get current legend alignment
`getLegendFontSize() -> int`	Get legend font size
`getMarkerSizeRange() -> Tuple[float, float]`	Get valid marker size range
`getSeriesData(name: str) -> List[Tuple[float, float]]`	Get data for a specific series (overrides base method)
`getSeriesLineStyle(name: str) -> str`	Get line style for a series
`getSeriesMarkerSize(name: str) -> float`	Get marker size for a specific series
`getSeriesMarkerStyle(name: str) -> str`	Get marker style for a series
`getSeriesNames() -> List[str]`	Get list of all series names (overrides base method)
`getXAxisRange() -> Tuple[float, float]`	Get X axis range
`getYAxisRange() -> Tuple[float, float]`	Get Y axis range
`gradientFill(args, *kwargs)`	Get gradient fill state
`gradientType(args, *kwargs)`	Get gradient type
`hasCustomMarkerSize(series_name: str) -> bool`	Check if series has custom marker size
`hideCrosshair()`	Manually hide crosshair
`hideTooltip()`	Manually hide tooltip
`isGradientFillEnabled() -> bool`	Check if gradient fill is enabled
`isPercentageArea() -> bool`	Check if percentage area is enabled
`isStackedArea() -> bool`	Check if stacked area is enabled
`isValidLineStyle(style: str) -> bool`	Check if line style is valid
`isValidMarkerStyle(style: str) -> bool`	Check if marker style is valid
`legendPositionChanged(...)`	Legend position changed.
`percentageArea(args, *kwargs)`	Get percentage area state
`printChart()`	Print chart
`refreshTheme()`	Refresh the current theme (useful when app palette changes)
`removeSeries(name: str) -> bool`	Remove a series from the chart
`resetMarkerSizes()`	Reset all marker sizes to default
`seriesAdded(...)`	Series added.
`seriesRemoved(...)`	Series removed.
`setAllMarkersSize(size: float)`	Set marker size for all series
`setAreaBorderEdges(enabled: bool)`	Draw the area polygon's full outline (True, default) or only the top
`setBaselineValue(value: float)`	Set the baseline value for area chart
`setChartTitle(title: str)`	Set chart title (compatibility method)
`setCrosshairColor(color: PySide6.QtGui.QColor)`	Set crosshair line color
`setCrosshairStyle(style: PySide6.QtCore.Qt.PenStyle)`	Set crosshair line style
`setCrosshairWidth(width: float)`	Set crosshair line width
`setFillOpacity(opacity: float)`	Set fill opacity (0.0 to 1.0)
`setGradientFill(enabled: bool)`	Enable or disable gradient fill
`setGradientType(gradient_type: str)`	Set gradient type: 'vertical', 'horizontal', or 'radial'
`setLegendAlignment(alignment: PySide6.QtCore.Qt.AlignmentFlag)`	Directly set legend alignment
`setLegendBackgroundVisible(visible: bool)`	Set legend background visibility
`setLegendFontSize(size: int)`	Set legend font size
`setPercentageArea(percentage: bool)`	Enable or disable percentage area chart
`setSeriesColor(name: str, color: PySide6.QtGui.QColor)`	Set color for a specific series (overrides base method)
`setSeriesLineStyle(name: str, style: str) -> bool`	Set line style for a series
`setSeriesLineWidth(name: str, width: float) -> bool`	Set line width for a series
`setSeriesMarkerSize(name: str, size: float) -> bool`	Set marker size for a series
`setSeriesMarkerStyle(name: str, style: str) -> bool`	Set marker style for a series
`setSeriesVisibility(name: str, visible: bool)`	Set visibility for a specific series (overrides base method)
`setStackedArea(stacked: bool)`	Enable or disable stacked area chart
`setXAxisRange(min_val: float, max_val: float)`	Set X axis range
`setXAxisTitle(title: str)`	Set X axis title
`setYAxisRange(min_val: float, max_val: float)`	Set Y axis range
`setYAxisTitle(title: str)`	Set Y axis title
`showCrosshairAt(x: float, y: float)`	Manually show crosshair at specific coordinates
`showTooltipAt(x: float, y: float, series_name: str, title: str = None, description: str = None)`	Manually show tooltip at specific coordinates
`stackedArea(args, *kwargs)`	Get stacked area state
`updateChart()`	Update the chart display based on current data
`updateSeriesData(name: str, data: List[Tuple[float, float]]) -> bool`	Update data for an existing series

Theming

Colours come from the design tokens, so they follow the active theme. Roles used: surface, on-surface, outline, accent.

See Design tokens.
