QCustomAnnotationWidget

QCustomAnnotationWidget (Canvas) is a powerful image annotation tool that provides a comprehensive drawing canvas for creating and managing annotations on images. It supports multiple shape types, Bezier curves, polygonal annotations, and exports annotations to JSON format for machine learning datasets.

Overview​

  • Multi-Shape Annotation:
    Supports rectangles, ellipses, lines, polylines, polygons, and Bezier curves.

  • Project Management:
    Organizes annotations into project folders with automatic image and JSON file management.

  • Real-time Drawing:
    Interactive drawing with live preview and smooth cursor tracking.

  • JSON Export:
    Exports annotations in standardized JSON format compatible with machine learning frameworks.

  • Zoom Capabilities:
    Built-in zoom functionality for detailed annotation work.

  • Label Management:
    Supports multiple labels and organizes shapes by label categories.

Constructor​

Canvas()

Creates a new annotation canvas with default settings.

Key Properties​

draw_shape (str)​

  • Purpose:
    Current drawing shape type.

  • Available Values:
    "rectangle", "ellipse", "line", "polyline", "bezier", "polygon"

pen_color (QColor)​

  • Purpose:
    Current drawing pen color.

current_label (str)​

  • Purpose:
    Current annotation label for newly drawn shapes.

project_folder (str)​

  • Purpose:
    Path to the project folder for saving annotations.

zoom_factor (float)​

  • Purpose:
    Current zoom level multiplier.

Methods​

setProjectFolder(folder)​

  • Description:
    Sets the project folder path for saving annotations and images.

  • Parameters:

    • folder: Path to project directory.

setLabel(label)​

  • Description:
    Sets the current label for new annotations.

  • Parameters:

    • label: Label name string.

setBackgroundImage(image_path)​

  • Description:
    Loads an image as the canvas background and loads existing annotations.

  • Parameters:

    • image_path: Path to the image file.

setPenColor(c)​

  • Description:
    Sets the drawing pen color.

  • Parameters:

    • c: Color string or QColor object.

setDrawShape(shape)​

  • Description:
    Sets the current drawing shape type.

  • Parameters:

    • shape: Shape type string.

saveData()​

  • Description:
    Saves all annotations to JSON file in the project folder.

  • Returns:
    True if successful, False otherwise.

  • Features:

    • Copies image to project "images" folder
    • Creates JSON annotation file
    • Groups shapes by labels
    • Maintains coordinate data

loadImageAnnotations(image_url)​

  • Description:
    Loads annotations from JSON file for the specified image.

  • Parameters:

    • image_url: Path to the image file.

deleteShapeFromJson(image_url, shape_to_delete)​

  • Description:
    Removes a specific shape from the annotation JSON file.

  • Parameters:

    • image_url: Path to the image file.
    • shape_to_delete: Shape tuple to remove.

  • Returns:
    True if successful, False otherwise.

readLabelsFromJsonFiles()​

  • Description:
    Reads all unique labels from all JSON files in the project folder.

  • Returns:
    Set of unique label strings.

updateCanvas(update=False)​

  • Description:
    Redraws the canvas with all shapes and current drawing preview.

  • Parameters:

    • update: If True, includes current drawing preview.

deleteShape(shape)​

  • Description:
    Removes a shape from the canvas and JSON file.

  • Parameters:

    • shape: Shape tuple to delete.

zoomIn()​

  • Description:
    Increases zoom level by 10%.

zoomOut()​

  • Description:
    Decreases zoom level by 10%.

exportToPng()​

  • Description:
    Exports the current canvas (image + annotations) as PNG file.

Signals​

shapeAdded(shape_type, color, label, coordinates)​

  • Description:
    Emitted when a new shape is added to the canvas.

  • Parameters:

    • shape_type: Type of shape drawn
    • color: Pen color used
    • label: Annotation label
    • coordinates: Shape coordinates list

Drawing Modes​

Rectangle & Ellipse​

  • Mouse Press: Set start point
  • Mouse Drag: Live preview
  • Mouse Release: Finalize shape

Line​

  • Mouse Press: Set start point
  • Mouse Drag: Live preview
  • Mouse Release: Finalize line

Polyline​

  • Left Click: Add point
  • Mouse Drag: Continuous drawing
  • Right Click: Finish polyline

Bezier Curve​

  • Left Click: Add control point
  • Mouse Drag: Adjust last control point
  • Right Click: Finish curve

Polygon​

  • Left Click: Add vertex
  • Mouse Drag: Adjust last vertex
  • Right Click: Finish polygon

Usage Example​

Basic Setup​

from Custom_Widgets.QCustomAnnotationWidget import Canvas

# Create canvas
canvas = Canvas()

# Set project folder
canvas.setProjectFolder("/path/to/project")

# Load image for annotation
canvas.setBackgroundImage("/path/to/image.jpg")

# Set annotation label
canvas.setLabel("person")

# Set drawing color
canvas.setPenColor("#ff0000")  # Red

# Set drawing shape
canvas.setDrawShape("rectangle")

Complete Annotation Workflow​

class AnnotationTool:
    def __init__(self):
        self.canvas = Canvas()
        self.setup_canvas()

    def setup_canvas(self):
        # Connect to shape added signal
        self.canvas.shapeAdded.connect(self.on_shape_added)

        # Set project structure
        self.canvas.setProjectFolder("my_annotation_project")

        # Set initial settings
        self.canvas.setLabel("object")
        self.canvas.setPenColor("#3498db")
        self.canvas.setDrawShape("rectangle")

    def load_image(self, image_path):
        self.canvas.setBackgroundImage(image_path)

    def on_shape_added(self, shape_type, color, label, coordinates):
        print(f"Shape added: {shape_type}, Label: {label}, Points: {len(coordinates)}")

    def save_annotations(self):
        if self.canvas.saveData():
            print("Annotations saved successfully!")
        else:
            print("Failed to save annotations.")

    def export_visualization(self):
        self.canvas.exportToPng()

Multi-Label Annotation​

# Switch between different labels
canvas.setLabel("vehicle")
canvas.setPenColor("#e74c3c")  # Red
canvas.setDrawShape("rectangle")

# Annotate vehicles...

canvas.setLabel("pedestrian")
canvas.setPenColor("#2ecc71")  # Green
canvas.setDrawShape("polygon")

# Annotate pedestrians...

# Save all annotations
canvas.saveData()

Loading Existing Annotations​

# Load image with existing annotations
canvas.setBackgroundImage("project/images/image_001.jpg")

# The annotations are automatically loaded from:
# project/image_001.jpg.json

# Get all unique labels in project
labels = canvas.readLabelsFromJsonFiles()
print("Available labels:", labels)

JSON Output Format​

Annotations are saved in this standardized format:

{
  "image_path": "images/sample.jpg",
  "annotations": [
    {
      "label": "person",
      "shapes": [
        {
          "type": "rectangle",
          "color": "#ff0000",
          "coordinates": [100, 150, 200, 300]
        },
        {
          "type": "polygon",
          "color": "#00ff00",
          "coordinates": [
            [150, 200],
            [180, 220],
            [160, 250],
            [140, 230]
          ]
        }
      ]
    }
  ]
}

Advanced Features​

Bezier Curve Mathematics​

  • Uses Bernstein polynomials for smooth curve calculation
  • Supports multiple control points
  • High precision with 1000 interpolation steps

Polygon Support​

  • Creates closed polygonal shapes
  • Useful for irregular object boundaries
  • Maintains vertex order and connectivity

Zoom Implementation​

  • Maintains aspect ratio during scaling
  • Smooth zoom transitions
  • High-quality image rendering

Event Handling​

  • Comprehensive mouse event management
  • Real-time drawing feedback
  • Context-aware right-click actions

Additional Notes​

  • Image Formats:
    Supports all image formats supported by Qt (PNG, JPG, BMP, etc.)

  • Coordinate System:
    Uses image pixel coordinates for precise annotation

  • Performance:
    Efficient redrawing with selective updates

  • Compatibility:
    JSON output compatible with popular ML frameworks (YOLO, COCO, etc.)

  • Error Handling:
    Robust error handling for file operations and invalid inputs

The QCustomAnnotationWidget is ideal for computer vision projects, machine learning datasets, image labeling applications, and any scenario requiring precise image annotation with export capabilities.
