QCustomEmbededWindow

QCustomEmbededWindow is a customizable embedded window widget that provides floating, draggable window functionality within a parent application. It features smooth animations, theme integration, and flexible content management.

Overview​

  • Floating Window System:
    Creates draggable, resizable embedded windows within a parent application.

  • Smooth Animations:
    Includes fade-in effects, height transitions, and smooth window operations.

  • Theme Integration:
    Automatically adapts to application themes with proper shadow and styling.

  • Flexible Content:
    Supports both custom widgets and pre-designed forms as window content.

  • Window Controls:
    Provides minimize/maximize and close functionality with standard icons.

  • Customizable Appearance:
    Configurable borders, headers, and animations.

Constructor​

QCustomEmbededWindow(parent, pos=None, title="New window", icon=None, borderRadius=10, headerHeight=25, animationDuration=500, showForm=None, addWidget=None)

  • parent:
    Parent widget where the embedded window will be displayed.

  • pos:
    Initial position as (x, y) tuple. Random position if not specified.

  • title:
    Window title text.

  • icon:
    QIcon for the window title bar.

  • borderRadius:
    Corner radius for rounded window appearance.

  • headerHeight:
    Height of the title bar in pixels.

  • animationDuration:
    Duration of animations in milliseconds.

  • showForm:
    Pre-designed form class to display in the window.

  • addWidget:
    Custom widget to add as window content.

Key Properties​

borderRadius (int)​

  • Purpose:
    Controls the corner radius for rounded window appearance.

headerHeight (int)​

  • Purpose:
    Height of the window title bar.

animationDuration (int)​

  • Purpose:
    Duration of window animations in milliseconds.

content_visible (bool)​

  • Purpose:
    Tracks whether the window content is currently visible.

Methods​

addWidget(widget)​

  • Description:
    Adds a custom widget to the window content area.

  • Parameters:

    • widget: QWidget to add as content.

  • Example:

    embedded_window.addWidget(custom_widget)

animateHeight(startHeight, endHeight)​

  • Description:
    Animates the window height transition.

  • Parameters:

    • startHeight: Starting height in pixels.
    • endHeight: Target height in pixels.

showHideContent()​

  • Description:
    Toggles the visibility of the window content with animation.

  • Behavior:

    • Shows/hides content area
    • Updates minimize/maximize button icon
    • Animates height transition

adjustSizeToContent()​

  • Description:
    Automatically adjusts window size to fit its content.

setShadow()​

  • Description:
    Applies a drop shadow effect based on current theme.

setTitle(text)​

  • Description:
    Sets the window title text.

  • Parameters:

    • text: New title string.

title()​

  • Description:
    Returns the current window title.

  • Returns:
    Current title string.

setControlsVisible(b)​

  • Description:
    Shows or hides the window control buttons.

  • Parameters:

    • b: Boolean to show/hide controls.

Signals​

closed()​

  • Description:
    Emitted when the window is closed via the close button.

  • Usage:
    Connect to this signal to handle window closure.

  • Example:

    embedded_window.closed.connect(self.on_window_closed)

Usage Example​

Basic Embedded Window​

from qtpy.QtWidgets import QApplication, QMainWindow, QLabel, QVBoxLayout
from Custom_Widgets.QCustomEmbededWindow import QCustomEmbededWindow

app = QApplication([])
main_window = QMainWindow()
main_window.setGeometry(100, 100, 800, 600)

# Create embedded window
embedded_win = QCustomEmbededWindow(
    parent=main_window,
    title="Information Panel",
    borderRadius=8,
    headerHeight=30
)

# Add content
content_label = QLabel("This is embedded window content")
embedded_win.addWidget(content_label)

main_window.show()
app.exec_()

With Pre-Designed Form​

from ui_forms.profile_form import Ui_ProfileForm

# Create window with form
profile_window = QCustomEmbededWindow(
    parent=main_window,
    title="User Profile",
    showForm=Ui_ProfileForm,
    animationDuration=300
)

# The form is automatically loaded and themed

Multiple Windows Management​

class WindowManager:
    def __init__(self, parent):
        self.parent = parent
        self.windows = []

    def create_window(self, title, content_widget=None, form_class=None):
        """Create a new embedded window"""
        window = QCustomEmbededWindow(
            parent=self.parent,
            title=title,
            showForm=form_class,
            addWidget=content_widget
        )

        # Connect close signal
        window.closed.connect(lambda: self.remove_window(window))

        self.windows.append(window)
        return window

    def remove_window(self, window):
        """Remove window from management"""
        if window in self.windows:
            self.windows.remove(window)
            window.deleteLater()

# Usage
manager = WindowManager(main_window)
notes_window = manager.create_window("Notes", notes_widget)
settings_window = manager.create_window("Settings", form_class=Ui_Settings)

Custom Styled Window​

# Create a themed embedded window
styled_window = QCustomEmbededWindow(
    parent=main_window,
    title="Custom Styled Window",
    borderRadius=15,
    headerHeight=35,
    animationDuration=400
)

# Apply custom styling
styled_window.setStyleSheet("""
    QCustomEmbededWindow {
        background-color: #2b2b2b;
        border: 1px solid #444;
    }
    #header {
        background-color: #404040;
        border-top-left-radius: 15px;
        border-top-right-radius: 15px;
    }
    #content-area {
        background-color: #2b2b2b;
        border-bottom-left-radius: 15px;
        border-bottom-right-radius: 15px;
    }
""")

Interactive Content​

class InteractiveEmbeddedWindow(QCustomEmbededWindow):
    def __init__(self, parent, data):
        super().__init__(parent, title="Data Viewer")

        self.data = data
        self.setup_content()
        self.connect_signals()

    def setup_content(self):
        # Create interactive content
        self.data_label = QLabel(str(self.data))
        self.refresh_btn = QPushButton("Refresh")
        self.close_btn = QPushButton("Close")

        layout = QVBoxLayout()
        layout.addWidget(self.data_label)
        layout.addWidget(self.refresh_btn)
        layout.addWidget(self.close_btn)

        content_widget = QWidget()
        content_widget.setLayout(layout)
        self.addWidget(content_widget)

    def connect_signals(self):
        self.refresh_btn.clicked.connect(self.refresh_data)
        self.close_btn.clicked.connect(self.close)

    def refresh_data(self):
        # Update content
        self.data_label.setText("Data refreshed at: " + str(datetime.now()))

# Usage
data_window = InteractiveEmbededWindow(main_window, initial_data)

Dynamic Window Positioning​

def create_staggered_windows(parent, count=3):
    """Create multiple windows with staggered positioning"""
    windows = []
    base_x, base_y = 50, 50
    offset = 30

    for i in range(count):
        window = QCustomEmbededWindow(
            parent=parent,
            pos=(base_x + i * offset, base_y + i * offset),
            title=f"Window {i+1}"
        )

        content = QLabel(f"This is window {i+1}")
        window.addWidget(content)
        windows.append(window)

    return windows

# Create staggered windows
windows = create_staggered_windows(main_window, 5)

Advanced Features​

Theme-Aware Shadows​

# Shadows automatically adapt to light/dark themes
# Light theme: Dark shadow
# Dark theme: Light shadow

Smooth Animations​

  • Fade-in: Smooth appearance when shown
  • Height transitions: Collapse/expand content
  • Easing curves: Natural motion with InSine easing

Drag and Drop​

  • Header dragging: Move window by dragging title bar
  • Boundary checking: Stays within parent bounds
  • Z-order management: Brings to front when interacted with

Content Management​

  • Automatic sizing: Adjusts to content dimensions
  • Form integration: Seamless loading of UI forms
  • Widget nesting: Supports complex widget hierarchies

Design Considerations​

Window Behavior​

  • Modal-like: Floats above parent content
  • Non-blocking: Doesn't block parent interaction
  • Self-contained: Manages its own state and content

Performance​

  • Efficient animations: Uses QPropertyAnimation for smooth performance
  • Memory management: Proper cleanup on closure
  • Event handling: Optimized mouse event processing

Customization Points​

  • Styling: Fully customizable via CSS
  • Icons: Replaceable control icons
  • Layout: Flexible content arrangement
  • Animations: Configurable timing and easing

Additional Notes​

  • Parent Relationship:
    Requires a parent widget for proper positioning and management.

  • Theme Integration:
    Automatically uses application theme engine for consistent styling.

  • Event Propagation:
    Properly handles mouse events for dragging and interaction.

  • Accessibility:
    Includes standard window controls with familiar behavior.

  • Extension Ready:
    Designed for subclassing and custom behavior implementation.

The QCustomEmbededWindow is ideal for applications requiring floating panels, tool palettes, inspector windows, modal dialogs, and any scenario where you need draggable, self-contained window functionality within a main application interface.
