QCustomGlassFrame
A GLASSMORPHISM / "liquid glass" container.
A rounded container that composites a BLURRED copy of the content behind it (the app's backdrop photo / wallpaper widget), then layers a tint, a film-grain noise pass, a hairline border and - opt-in - a "liquid" edge (refraction ring + specular rim) on top. Children laid out inside it sit on frosted glass, like CSS backdrop-filter or visionOS panels.
Qt has no native backdrop-filter, so the frame renders a SOURCE widget into a pixmap, blurs it offscreen (downsample -> QGraphicsBlurEffect -> upsample) and paints that region under its own content:
backdropSource(objectName) / setBackdropWidget(w): the widget to sample - typically the full-window photo QLabel BELOW the glass panels. Sampling a widget that does not contain the frame is cheap and flicker-free, soliveBackdropcan re-sample continuously.- With no source set, the frame samples its own top-level window (hiding itself for the grab). That path is for static backdrops - refresh happens on show/resize/move or an explicit refreshBackdrop().
- With nothing to sample (Designer palette preview, render_widget), it paints a seeded placeholder gradient so it still previews.
Every knob is a typed Designer property; colours are qproperties so QSS
drives them per theme (qproperty-tintColor: ...). The live re-sampling
"animation" is user-controllable via liveBackdrop + refreshInterval.
At a glance
| Tier | Free (GPLv3) |
| Import | from Custom_Widgets.QCustomGlassFrame import QCustomGlassFrame |
| Qt Designer | Yes — drag it from the palette |
Quick start
from Custom_Widgets.QCustomGlassFrame import QCustomGlassFrame
widget = QCustomGlassFrame()
Dark theme
Colours come from the design tokens, so the widget follows the app theme with no extra work.
Properties
Every property below is settable in code and in Qt Designer.
| Property | Type | Default |
|---|---|---|
frameShape | QFrame::Shape | — |
frameShadow | QFrame::Shadow | — |
lineWidth | int | — |
midLineWidth | int | — |
frameWidth | int | — |
frameRect | QRect | — |
backdropSource | string | — |
blurRadius | int | 28 |
downsample | int | 3 |
tintColor | color | rgba(18,22,32,110) |
brightness | float | 1.0 |
noiseOpacity | float | 0.05 |
cornerRadius | int | 24 |
borderColor | color | rgba(255,255,255,55) |
borderWidth | float | 1.0 |
liquidEdge | bool | False |
edgeIntensity | float | 0.5 |
liveBackdrop | bool | False |
refreshInterval | int | 120 |
Methods
| Method | Description |
|---|---|
backdropSource(*args, **kwargs) | Backdrop source. |
blurRadius(*args, **kwargs) | Blur radius. |
borderColor(*args, **kwargs) | Border color. |
borderWidth(*args, **kwargs) | Border width. |
brightness(*args, **kwargs) | Brightness. |
changeEvent(e) | Change event. |
cornerRadius(*args, **kwargs) | Corner radius. |
downsample(*args, **kwargs) | Downsample. |
edgeIntensity(*args, **kwargs) | Edge intensity. |
eventFilter(obj, e) | Event filter. |
liquidEdge(*args, **kwargs) | Liquid edge. |
liveBackdrop(*args, **kwargs) | Live backdrop. |
moveEvent(e) | Move event. |
noiseOpacity(*args, **kwargs) | Noise opacity. |
refreshBackdrop() | Re-sample and re-blur the backdrop now. |
refreshInterval(*args, **kwargs) | Refresh the interval. |
setBackdropWidget(widget) | Point the frame at the widget to sample (overrides backdropSource). |
tintColor(*args, **kwargs) | Tint color. |
