QCustomFlowWidget

A container widget that uses QCustomFlowLayout internally.

ALL custom properties are exposed here for Qt Designer.

At a glance


Tier	Free (GPLv3)
Import	`from Custom_Widgets.QCustomFlowWidget import QCustomFlowWidget`
Qt Designer	Yes — drag it from the palette

from Custom_Widgets.QCustomFlowWidget import QCustomFlowWidget

widget = QCustomFlowWidget()
for chip in _flowChips():
widget.addWidget(chip)

That is the exact code behind the screenshot above.

Colours come from the design tokens, so the widget follows the app theme with no extra work.

Every property below is settable in code and in Qt Designer.

Method	Description
`addWidget(widget, position=None)`	Add a widget to the flow layout
`adoptExistingChildren()`	Adopt existing child widgets from Qt Designer in their original order
`animationDuration(args, *kwargs)`	Animation duration.
`animationEasingCurve(args, *kwargs)`	Animation easing curve.
`animationEnabled(args, *kwargs)`	Animation enabled.
`autoFillHeight(args, *kwargs)`	Auto fill height.
`autoFillWidth(args, *kwargs)`	Auto fill width.
`childEvent(event)`	Handle child events to detect when widgets are added
`clear()`	Remove all widgets from the flow layout
`equalDistribution(args, *kwargs)`	Equal distribution.
`getFlowLayout()`	Get the underlying flow layout
`horizontalSpacing(args, *kwargs)`	Horizontal spacing.
`isAnimating()`	Check if animations are running
`justifySpacing(args, *kwargs)`	Justify spacing.
`margin(args, *kwargs)`	Margin.
`orderJsonPath(args, *kwargs)`	Order json path.
`refreshLayout()`	Manually refresh the layout
`removeWidget(widget)`	Remove a widget from the flow layout
`spacing(args, *kwargs)`	Spacing.
`stopAllAnimations()`	Stop all ongoing animations
`verticalSpacing(args, *kwargs)`	Vertical spacing.

A complete app using this widget lives at examples/PySide6/QCustomFlowWidget/main.py.
