QCustomDrawer

A slide-in side panel / sheet.

A dimmed overlay with a panel that slides in from an edge (left / right / top / bottom). Backdrop-click or Esc closes it. Tokenized.

drawer = QCustomDrawer(window, side="left", size=280) drawer.contentLayout().addWidget(nav) drawer.open()

At a glance


Tier	Free (GPLv3)
Import	`from Custom_Widgets.QCustomDrawer import QCustomDrawer`
Qt Designer	Yes — drag it from the palette

from Custom_Widgets.QCustomDrawer import QCustomDrawer

widget = QCustomDrawer()

Colours come from the design tokens, so the widget follows the app theme with no extra work.

Every property below is settable in code and in Qt Designer.

Property	Type	Default
`side`	`enum:` left`/`right`/`top`/`bottom``	`left`
`drawerSize`	`int`	—

Signal
`closed()`
`opened()`

Method	Description
`addWidget(widget)`	Add a widget.
`close()`	Close.
`closed(...)`	Closed.
`contentLayout()`	Content layout.
`drawerSize(args, *kwargs)`	Drawer size.
`isOpen()`	Return whether the widget is open.
`open()`	Open.
`opened(...)`	Opened.
`side(args, *kwargs)`	Side.

Colours come from the design tokens, so they follow the active theme. Roles used: surface, on-surface, outline.
